| Resolution | 203 DPI |
Print Method | Direct Thermal |
| Memory | 8 MB RAM / 8 MB Flash |
| Max.Print Width | 4.25 in. / 108 mm |
| Max.Print Speed | Up to 6 ips (152 mm/s) |
| Media Sensors | Fixed Black Mark Sensor / Fixed Gap Sensor |
| Emulation | TSPL, ZPL, EPL, DPL |
| Interface | USB, USB+Serial, USB+Lan, Optional Wireless Connectivity: Bluetooth / Wi-Fi |
| Others | Optional RTC, Optional SD Card Slot |
Media and Ribbon Characteristics | |
Media Length | 0.39 in.~70 in.(10 mm ~ 1778 mm) |
Media Width | 1 in. - 4.56 in. (25.4 mm - 116 mm) |
Media Roll Size | 5 in./127 mm Outer Diameter Core Inner Diameter: 1 in. (25.4 mm) - 1.5in. (38.1mm) |
Media Thickness | 0.0023 in.(0.06 mm) Min.; 0.01 in.(0.254 mm) Max. |
Media Types | Continuous, Gap, Black mark, Fan-fold, Perforated Media |
Environment Condition | |
Operating Temp. | 5~40?(41~104°F) |
Storage Temp. | -40~60?(-40~140°F) |
Operating Humidity | 25 ~ 85% Non-Condensing |
Storage Humidity | 10 ~ 90% Non-Condensing |
Fonts/Graphics/Symbologies | |
1D Bar Codes | Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar,Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E,EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 |
2D Bar Codes | PDF-417, Maxicode, DataMatrix, QR code, Aztec |
Fonts and Graphics | Font 0 ~ Font 8 |
Software | |
Driver | Windows /Linux /Mac / Android / Chrome OS |
SDK | Windows/Linux / Android / iOS |
Software | Bartender UltraLite / Mobile Label Design App |
Accessories | |
Standard Accessories | Power Adapter, Power Cord, USB Cable, User Manual, CD, Label spindle, Fixing tab |
Factory Installed Options | Bluetooth Module, Wi-Fi Module |
User Options | 8" External Paper Roll Holder |
Product Warranty | |
Printhead life | The earlier of 30 km usage or 1 year |
Platen roller life | The earlier of 30 km usage or 1 year |
Printer Warranty | 1 Year |
Physical Characteristics | |
Dimension | 219 mm * 189.6 mm * 178.5 mm (D * W * H) |
Weight | 1.4 Kg |
